Technische Daten

ASBESTOS-FREE FLEXIBLE FRICTION MATERIALS IN ROLLS OR SHEETS, THICKNESSES from 1.5 mm to 14.0 mm

FLEXIBLE MATERIALS COMPOSITION APPLICATIONS DENSITY
(G/CM³ )
  AVERAGE FACTOR OF FRICTION u
<250°
SURFACE PRESSURE
P (N/CM)
RUBBING SPEED
V (M/S)
TEMPERATURE
(SHORT TIME) °C
TEMPERATURE
(CONTINUOUS) °C
OIL
RESISTANCE
Beral 1105 Asbestos free, flexibles friction material, elastomer bonded without metal fibers Drum brake linings for industrial applications, motorcycles, commercial vehicles and CVT clutches 2,10 0,53 15-150 <30 <400 <250 poor
Beral 1106 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Drum brake linings for motorcycles and industrial brake applications, commercial vehicles, CVT clutches and passenger car handbrakes 2,20 0,54 10-150 <30 <400 <250 poor
Beral 1109 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Drum brake linings for motorcycles, passenger cars, car/trailer combinations and crane brakes 2,10 0,48 10-150 <30 <350 <200 poor
Beral 1117 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Drum brake linings for motorcycles, fork lifts, industrial applications, commercial vehicles and agriculture axles 2,20 0,43 5-150 <30 <380 <280 poor
Beral 1121 Asbestos free, flexible friction material, elastomer bonded without metal fibers Electromagnetic clutches and brakes, industrial brakes, suitable as a friction material against soft iron and steel 2,10 0,40 15-100 <30 <350 <250 poor
Beral 1122 Asbestos free, flexible friction material, elastomer bonded without metal fibers Electromagnetic clutches and brakes, industrial brakes, suitable as a friction material against soft iron and steel. Suitable for use in oil. 2,02 0,40 a dry 0,10 wet 15-100 <25 <350 <250 very good
Beral 1126 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Drum brake linings for motorcycles and car trailers, friction linings for CVT clutches and industrial applications 2,30 0,45 10-150 <30 <400 <250 poor
Beral 1127 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Service brakes and handbrakes for passenger cars and commercial vehicles 2,10 0,45 10-150 <30 <400 <250 poor
Beral 1129 Asbestos free, flexible friction material, elastomer bonded without metal fibers Electromagnetic clutches and brakes, industrial brakes, lift applications, friction washers for oscillation damping systems 2,19 0,50 5-150 <30 <350 <250 poor
Beral 1130 Asbestos free, flexible friction material, elastomer bonded and metal fiber reinforced Drum brakes for passenger cars and commercial vehicles, motorcycles, CVT clutches, agriculture axles 2,30 0,52 10-150 <30 <400 <250 poor
Beral 1137 Asbestos free, flexible friction material, elastomer bonded without iron fibers Drum brake linings for lorries, commercial vehicles, car/trailer combinations, fork lifts, industrial applications, electromagnetic brake, agriculture axles 2,20 0,43 10-200 <30 <450 <250 poor
Beral 1150 Asbestos free, flexible friction material, elastomer bonded without metal fibers Electromagnetic brakes and clutches, outside shoe brakes, especially used for steel or soft iron mating materials 1,80 0,52 15-150 <30 <350 <200 poor

ASBESTOS FREE MOULDED FRICTION MATERIALS IN RIGID SHEETS, THICKNESSES from 1.5 mm to 20.0 mm

Moulded Material COMPOSITION APPLICATIONS DENSITY
(G/CM³ )
  AVERAGE FACTOR OF FRICTION u
<250°
SURFACE PRESSURE
P (N/CM)
RUBBING SPEED
V (M/S)
TEMPERATURE
(SHORT TIME) °C
TEMPERATURE
(CONTINUOUS) °C
OIL
RESISTANCE
EBB 7250 Rigid moulded, asbestos free friction material on a elastomeric/resin matrix, reinforced with synthetic fibers, without metal components Brake shoes and disk brakes for the mechanical engineering sector, clutch an brake combinations, suitable for high rubbing speed applications 1,90 0,47 15-400 <40 <400 <250 poor
EBB 7260 Rigid moulded, asbestos free friction material on a elastomeric/resin matrix, reinforced with synthetic fibers and without metal components. The specific weight is very low Brake and friction linings for industrial applications. Suitable for wet applications. 1,50 0,35 15-350 <50 <400 <250 Very good
EBB 7270 Rigid moulded, asbestos free friction material on a elastomeric/resin matrix, reinforced with synthetic fibers and no magnetic metal Rigid drum brake linings, Servo brakes 2,40 0,45 30-1000 <40 <400 <250 poor
